HP612A The elasticity (hardness) tester

The elasticity (hardness) tester is suitable for measuring the hardness, elasticity, etc. of different products such as food, medicine, chemical, and agricultural products, providing reference data for selecting product formulas and processes. It is also known as a hardness tester, elasticity tester, etc.

Testing principle of elasticity (hardness) tester:

The tester conducts a downward pressure test on the product to determine its hardness and resilience in different states; To confirm its hardness and toughness.

Characteristics of elasticity (hardness) tester:

1. The touch screen display displays real-time force values, displacement deformation, fully automatic testing, and automatically saves the maximum value of the current test; The display interface can display the test curve in real time; Test real-time parameters such as speed and deformation.

2. Using a high-precision, fully digital speed control system and precision reducer, the precision screw pair is driven for testing, achieving a wide range of adjustment of the test speed and smooth operation.

3. Adopting high-precision sensors and professional measurement and control software, with high testing accuracy, wide testing range, and simple operation.

4. Equipped with a standard micro printer, it can print results at any time and can calculate multiple test results, maximum, minimum, and average values.

5. After selecting a computer, the software curve and test results are displayed on the same interface, including the curve and test data. Test data such as force, time, distance, and software displayed synchronously during the testing process. Data analysis, result data and curves, can store data infinitely, and can print A4 reports.

Technical parameters of elasticity (hardness) tester:

Measurement range: 50 N (optional for 100 N, 500 N, or 1000 N)

Resolution: 0.1N

Accuracy: ± 0.5%

Test speed: (1-300) mm/min

Upper pressure head: 10mm pressure head

Parallel upper and lower pressure plates:<0.025mm

Lower pressure plate diameter: 120 mm

External dimensions: 430 x 350 x 710mm

Mass: 45kg

Power supply: 220V, 50Hz

Elastic (hardness) tester configuration

Standard configuration: Elastic (hardness) tester host, testing aids, micro printer. (Single machine can also be used)

Purchase: Lenovo computers, inkjet printers, online computer control software.

Touch screen display diagram of elasticity (hardness) tester
