HP-NLY-20C The torque tester

Product Introduction

The torque tester is an instrument designed in accordance with the relevant national standards for packaging bottle caps. Suitable for testing the torque value of bottle cap locking and opening for packaging products such as beverage bottles, mineral water bottles, milk bottles, oil drums, etc. This product is suitable for torque testing of bottle caps on packaging containers with standard circular or symmetrical shapes. It can achieve bidirectional testing of torque force by clockwise and counterclockwise rotation, and automatically record the maximum torque force value. The torque tester is widely used in quality inspection institutions, food, pharmaceuticals, cosmetics and other industries.

Product features

High definition touch screen operation, simple and feasible, with strong sense of technology

Conventional power supply, universal interface connection, convenient to use

Microcomputer control technology, open architecture, user-friendly human-machine interface operation, simple and convenient to use

Single group, multi group testing mode, automatic statistics of test results

Two measurement modes for locking force and opening force, achieving multiple uses for one machine

Built in multiple units, N • m, kg • cm, ib • in can be freely converted

Force retention function, which can retain the maximum test value

Result storage function, capable of storing up to 400 sets of test results for easy querying

Using high-precision torque sensors with a measurement accuracy of 0.5% F.S

LCD Chinese display, high-resolution clear screen display

Equipped with peak alarm to ensure orderly testing

Built in dedicated calibration program for easy calibration of instruments by metrology and calibration departments (third-party)

Third level account login, clear permissions, in compliance with pharmacopoeia regulations

The needle printer outputs result data, and the printed results can be retained for a long time, meeting the requirements of the pharmacopoeia

Real time display of interface curves for effective monitoring of testing progress

technical parameter

Measurement range: 0-5.0N • m 0-51kg • cm 0-44.25ib • in

Measurement unit: N • m kg • cm ib • in

Measurement accuracy: 0.5% F.S

Measurement modes: peak test (opening force), fixed value test (tightening force)

Clamping size: 3-180mm

Data storage: 400 sets

Operation mode: 4.3-inch capacitive touch screen

Screen resolution: 800x480

External dimensions: 420 (L) x 230 (W) x 245 (H) mm

Power supply: 220V 50Hz

Weight: approximately 10kg

Standard configuration: host, power cord, fuse, wrench, printing paper

Execution standards

GBT 17876, BBT 0025, BBT 0034 (GBT 14803) YBB 00112002-2015、YBB 00122002-2015、YBB 00262002-2015、ASTM D 2063、ASTM D 3198、ASTM D 3474
